Userguide
Overview
There are two main steps in configuring a simulation.
Drug and model selection
All the availiable drug models follow the same import format.
import opentiva.*drug* as *drug*
drug_model = *drug*.*Model*(sex, age, weight, height)
The parameters are:
Parameter |
Type |
Description |
|---|---|---|
Sex |
int |
0 for male or 1 for female |
Age |
int |
in years |
Weight |
float |
in kg |
Height |
float |
in cm |
List of availiable models can be found here.
Note
Some models require extra parameters; for example, propofol Eleveld’s opiates_coadministered bool (True if opiate coadministration) or rocuronium Kleijn’s sevoflurane, asian and creatinine parameters.
Examples
Importing:
import opentiva.propofol as propofol
import opentiva.remifentanil as remifentanil
sex = 0 # male
age = 30 # years
weight = 70 # kg
height = 170 # cm
propofol_schnider = propofol.Schnider(sex=sex, age=age,
weight=weight, height=height)
propofol_eleveld = propofol.EleveldWithoutOpiates(sex=sex, age=age,
weight=weight, height=height)
remifentanil_minto = remifentanil.Minto(sex=sex, age=age,
weight=weight, height=height)
Returning a model’s pharmokinetic/ pharmacodynamic values:
import opentiva.remifentanil as remifentanil
sex = 0 # male
age = 30 # years
weight = 70 # kg
height = 170 # cm
remifentanil_minto = remifentanil.Minto(sex=sex, age=age,
weight=weight, height=height)
print(remifentanil_minto.compartments)
# Number of compartments that the model uses
print(remifentanil_minto.k12)
# Equilibrium rate constant from compartment 1 to 2
print(remifentanil_minto.ke0)
# Effect compartment equilibrium rate constant
All the availiable exportable pharmokinetic/ pharmacodynamic values can be found here.
Returning a model’s warnings:
Warnings will be generated when a models validated anthropometric values are not met. These will written to sys.stderr and returned as a string.
import opentiva.propofol as propofol
sex = 1 # female
age = 5 # years
weight = 18 # kg
height = 109 # cm
propofol_marsh = propofol.MarshDiprifusor(sex=sex, age=age,
weight=weight, height=height)
warning = propofol_marsh.warning
print(warning)
Pump configuration
The pump class has a range of required and optional settings that determine how the simulation runs.
A minimal example of the required parameters is:
import opentiva.propofol as propofol
import opentiva.pump as pump
propofol_eleveld = propofol.Eleveld(sex=0, age=30,
weight=70, height=170,
opiates_coadministered=False)
p1 = pump.Pump(model=propofol_eleveld,
drug_concentration=10,
end_time=(60*60))
Parameter |
Type |
Description |
|---|---|---|
model |
Class object |
opentiva pharmacokinetic/ pharmacodynamic model |
drug_concentration |
float |
concentration of infusion drug (using units outlined in model; model.concentration_unit) |
end_time |
int |
duration of simulation in seconds |
The optional settings relate to defaults for effect site targetting, maintenance infusions and characteristics of the simulated pump.
Full API reference can be found here.
The effect site targetting parameters (cp_limit and cp_limit_duration) are covered here. The values given in the pump class initialization are used as defaults if these are not supplied for an individual target.
Maintenance infusions
The maintenance infusion is the infusion required to offset the clearance and distribution losses to maintain a steady state plasma and effect site concentration.
As the time in a steady state increases the exponential nature of the two/ three compartment model means the changes between the amount of drug being infused by the each subsequent maintenance infusions decreases.
maintenance_infusion_duration int default 300 seconds
Time in seconds of the duration of each maintenance infusion
maintenance_infusion_multiplier float default 2
The duration of each subsequent maintenance infusion is multiplied by this, extending the time between each maintenance infusion calculation.
This reduces the number of infusions required and computing load, but may result in periods of time below a target.
Pump characteristics
max_infusion_rate float default 1200 ml/hr
Maximum rate in ml/hr that the pump can deliver an infusion. If a calculated infusion rate is higher than this it will be limited to this rate. This can increase the time to achieve a target plasma and effect site concentration.
bolus_time int default 20 seconds
If the duration of an infusion is less than this time the dose will be considered as being given as a bolus and the rate of infusion will not be limited by the set maximum infusion rate.
Full example
import opentiva.propofol as propofol
import opentiva.pump as pump
propofol_paedfusor = propofol.Paedfusor(sex=0, age=5,
weight=18, height=109)
p1 = pump.Pump(model=propofol_paedfusor,
drug_concentration=10, # propofol concentration of 10 mg/ml
end_time=(2*60*60), # total duration of simulation is 2 hours
maintenance_infusion_duration=10, # first maintenance infusion is 10 seconds in duration
maintenance_infusion_multiplier=2, # the duration of each subsequent maintenance infusion is doubled
cp_limit = 1.2, # maximum plasma concentration during effect targetting is 1.2 x the target
cp_limit_duration = 10, # duration to achieve cp_limit is 10 seconds
max_infusion_rate = 1200, # maximum rate of pump is 1200 ml/hr
bolus_time = 20) # any infusion < 20 seconds in duration is considered a bolus dose
Target configuration
Once the drug/ model and pump have been initialized target concentrations can be added. These can target either the plasma or effect site.
This is achieved by using the add_target function.
import opentiva.pump as pump
p1 = pump.Pump(...)
p1.add_target(...)
Plasma site targetting
In plasma site targetting opentiva calculates the infusion required to reach the plasma target concentration after a specified duration.
p1.add_target(start=0, target=4, duration=10, effect=False)
The above example will reach a plasma concentration of 4 after 10 seconds starting from 0 seconds.
Parameter |
Type |
Description |
|---|---|---|
start |
int |
start time of target in seconds |
target |
float |
target of plasma or effect concentration |
duration |
int |
time to achieve target level in seconds |
effect |
bool: default True |
true for effect site targetting or false for plasma site targetting |
Effect site targetting
In effect site targetting there are two methods availiable to calculate the infusions required to reach the effect site concentration.
Original
Original method described by Shafer et al.
An infusion is given over a duration (Cp_limit_duration) which causes an overshoot in plasma concentration. This overshoot decreases the time to reach a specified effect site target (Cetarget) compared to plasma targetting mode.
Example:
p1.add_target(start=0, target=4, duration=10, effect=True,
cp_limit_duration=20, ce_bolus_only=True)
The above example will calculate the bolus dose over 20 seconds to achieve a rapid rise to an effect site of 4 with minimal effect site overshoot.
Parameter |
Type |
Description |
|---|---|---|
cp_limit_duration |
int |
duration in seconds to achieve the maximal plasma concentration, will override the value given in pump initialization |
ce_bolus_only |
bool |
true for Original method (bolus only) effect targetting or false for revised method |
Revised
Revised effect targetting aims to decrease the overshoot in plasma concentration; based on Van Poucke et al.
To achieve a target effect site (Cetarget) an initial infusion to reach a maximal plasma target (Cpmax) is given. This plasma target is set by the multiplying the target effect concentration by a limit value (Cplimit). Once at this maximum plasma concentration a maintenance infusion is started to maintain steady state over time (Tinf). At a certain point in time stopping the maintenance infusion will result in the plasma concentration decrementing over time (Tcoast) to the effect target concentration which will be met at the same time as the up trending effect site concentration.
Example:
p1.add_target(start=0, target=4, duration=10, effect=True,
cp_limit=1.5, cp_limit_duration=20,
ce_bolus_only=True)
The above example will increase to a plasma concentration of 6 over 20 seconds. This is then maintained at 6 over a calculated duration then stopped. After stopping the decrement of the plasma concentration meets the increasing effect site concentration at the target of 4.
Parameter |
Type |
Description |
|---|---|---|
cp_limit |
float |
multiplied to the target to get maximum increase in plasma concentration; value will override the value given in pump initialization |
Note
Optimal value for cp_limit: The maximum value of cp_limit can be found by first running the simulation with the target reached by the original method (ce_bolus_only=True). Above this calculated cp_limit an overshoot in effect site concentration would occur. After generating infusions (generate_infusions()) or running the simulation (run()) the calculated cp_limit can be obtained from the target_concentration array. Then the cp_limit for the revised targetting can be set a value less than this.
Duration in effect targetting
The duration parameter will only have an influence on effect site targetting if it is longer then the minimum time it takes to reach a target.
For example, if it takes 250 seconds for a effect site target to be reached by the original method.
A duration of 10 seconds will be ignored.
A duration of 300 seconds will change the infusions so that the effect site target is reached at approximately 300 seconds.
Maintenance infusions
By default opentiva will calculate the maintenance infusions required to maintain steady state from when the target is reached to the next set target.
To disable this set maintenance_infusions as False:
p1.add_target(start=0, target=4, duration=10, effect=True,
cp_limit=1.5, cp_limit_duration=20, ce_bolus_only=True,
maintenance_infusions=False)
The above example does the same as the revised effect site targetting example but will not maintain a steady state after the target is reached.
Parameter |
Type |
Description |
|---|---|---|
maintenance_infusions |
bool: default True |
true will calculate the infusions between the time the target is reached and the next target to maintain steady state |
Run simulation
The simulation can then be run by using the run function:
output = p1.run()
This returns a 2d numpy array of:
Column |
Description |
|---|---|
1 |
time in seconds of concentration |
2 |
plasma concentration |
3 |
effect site concentration |
To generate the infusions required to meet the targets and not calculate the plasma and effect site concentrations the following function can be used.
p1.generate_infusions()
See Exporting data on how to export the infusions.
Putting it all together
A full example is show below:
import opentiva.propofol as propofol
import opentiva.pump as pump
adult35 = propofol.Eleveld(sex=0, age=35,
weight=70, height=170,
opiates_coadministered=False)
p1 = pump.Pump(model=adult35,
drug_concentration=10,
end_time=(1*60*60),
maintenance_infusion_duration=10,
maintenance_infusion_multiplier=2,
cp_limit = 1.2,
cp_limit_duration = 10,
max_infusion_rate = 1200,
bolus_time = 20)
# Target Ce 3 using revised method at time 0
p1.add_target(start=0,
target=3,
duration=10,
effect=True,
cp_limit=5.0,
cp_limit_duration=10,
ce_bolus_only=False)
# Reduce to Ce 2.5 at 5 minutes (300 seconds)
p1.add_target(start=300,
target=2.5,
duration=10,
effect=True)
# Target Cp 4 at time 10 minutes (600 seconds) over 1 minute
p1.add_target(start=1200,
target=4,
duration=60,
effect=False)
# Reduce to Cp 2 at time 50 minutes (3000 seconds) then stop the
# maintenance infusions
p1.add_target(start=3000,
target=2,
duration=10,
effect=False,
maintenance_infusions=False)
# Simulated plasma and effect site concentrations
concentrations = p1.run()
print("\nConcentrations"
"\n=============="
"\nColumn 0: Time (seconds)"
"\nColumn 1: Plasma concentration"
"\nColumn 2: Effect site concentration")
print(concentrations)
# Infusion List
print("\nInfusion list"
"\n============="
"\nColumn 0: Start time (seconds)"
"\nColumn 1: Dose (mg) per second"
"\nColumn 2: Duration (seconds)"
"\nColumn 3: End time (seconds)\n")
print(p1.infusion_list)
# Rates list
rates = p1.generate_rates_array()
print("\nRates"
"\n====="
"\nColumn 0: Time (seconds)"
"\nColumn 1: Rate (ml/hr)\n")
print(rates)
